Swansea Astronomical Society Blog

Saturday, July 20, 2013



Eyepiece projection with a 130mm, f/5 Newtonian and lunar results with a cheap spotting scope

A Pentax K-x DSLR was fitted with an eyepiece projection adapter and a 15mm, wide angle lens and attached to a 130mm, f/5 Newtonian. Two overlapping images of the Moon were captured at ISO 100 and 1/20s exposure. A remote control was used to fire the shutter when all vibration had dampened down. The two images were combined into a single image. Click on the image to get a larger view:


An experiment was done with a 60mm 20x-60x zoom, spotting scope purchased from an Aldi store for £26-99.




Even a low cost device intended for nature study can yield results. Another project is to build an afocal rig to attach a DSLR for eyepiece projection or a digiscoping rig to fit the large diameter eyepiece.

A Fujifilm Finepix F450 compact camera was handheld to the eyepiece and a single image was captured:



Steve Wainwright

Friday, July 19, 2013



AR1793 with a 120mm refractor

A DMK31AS camera was used with an 120mm ED refractor fitted with a Baadere solar filter. The camera was placed at prime focus and also with a 2.5x Barlow:

Prime focus

 2.5x Barlow


Keith Davies


Thursday, July 18, 2013



Lunar imaging with a DSLR and an f/5, 130mm Newtonian

It is not possible to place a DSLR at the prime focus of the f/5, 130mm Newtonian and bring it to focus. Eyepiece projection is one way of bringing the Moon to focus.


The eyepiece projection adapter:


18mm eyepiece fitted in the adapter:

The camera was set to capture a movie at 1200 x 700 resolution:

A 4000 frame AVI was captured

The AVI captured by the Pentax K-x cannot be processed by Registax. However, if it is loaded into Virtual Dub, an AVI can be saved out from Virtual Dub that can be processed by Registax.
The AVI was processed in Registax to produce the final image. Click on the image to get a larger view:

Steve Wainwright

Wednesday, July 17, 2013



The Sun in white light using 1280 x 720 video with a DSLR

A Pentax K-x DSLR was placed at the prime focus of an f/10, 127mm Maksutov fitted with a photographic grade Baader solar filter. A 3432 frame AVI was captured at a resolution of 1280 x 720. The AVI was processed in Registax to produce the final image. Click on the image to get a larger view.



Three groups of sunspots can be seen
Ar1793 was imaged in more detail using eyepiece projection with a 20mm Plossl. A 3000 frame AVI was captured and processed in Registax:



Steve Wainwright


M13 with a 6" SCT and a starshoot camera

An Orion Starshoot colour camera was used with a wedge mounted 6", f/10 SCT to image M13. 20 x 40s light and dark frames were captured. The images were stacked in Deep Sky stacker:


Colin Miles



A 59% full, waxing, gibbous Moon in the daytime sky

A handheld Pentax K-x DSLR, fitted with a 300mm lens was used to capture an image of the Moon in a slightly cloudy daylight sky:


Placed at the prime focus of an f/10, 127mm Maksutov, the DSLR was set to ISO100 and 1/50s. 10 RAW images were captured, resized and converted to TIFF files. The tiffs were stacked in Registax to produce the final image. Click on the image to get a larger view:


Steve Wainwright

Tuesday, July 16, 2013



M57 with a 6" SCT

Twenty, 40s exposures using light and dark frames were captured of the Ring Nebula using an Orion Starshoot camera and a 6" SCT.  The images were stacked in Deep Sky Stacker (which used 19 of them) followed by post processing:


Colin Miles

Monday, July 15, 2013



48% waxing, crescent Moon

A Pentax K-x DSLR was placed at the prime focus of an f/10, 127mm Maksutov on a driven equatorial mount. The camera was set to ISO100 and 0.3s exposure. The camera was focused in zoomed live mode and a single RAW image was captured. Click on the image to get a larger view:


Steve Wainwright



A high latitude hedgerow prominence on July 13 and 14

A Lunt 60mm H-alpha scope with a Lumenera camera fitted with stacked 2x Barlows was used to image a high latitude solar prominence on July 13th and July 14th.
July 13th



July 14th


There appears to have been little rotation over a 24h period

Derek Francis


Sunday, July 14, 2013



37% full, waxing, crescent Moon

A Pentax K-x DSLR was placed at the prime focus of an f/10, 127mm Maksutov. The camera was set to ISO 100 and 1/10s and 25 RAW images were captured. The images were stacked in Registax to produce the final image:


Steve Wainwright
